2026 Honda FourTrax Rancher 4x4 Automatic DCT IRS EPS

The 2026 Honda FourTrax Rancher 4x4 Automatic DCT IRS EPS adds Dual-Clutch Transmission, independent rear suspension, and electric power steering to the 420cc Rancher. Seat height is 35.4 inches and the published curb weight is 686 pounds.

Front travel is 7.3 inches, compared with 6.7 inches on the manual Rancher 4x4. The 2027 Rancher Automatic DCT EPS keeps the DCT and power steering but not this independent rear suspension, and it is listed at 642 pounds with a 33.6-inch seat.

Specifications

• Engine Type
  420cc liquid-cooled longitudinally mounted single-cylinder four-stroke
• Bore And Stroke
  86.5mm x 71.5mm
• Compression Ratio
  9.9:1
• Valve Train
  OHV; two valves per cylinder
• Induction
  Programmed Fuel Injection system (PGM-FI); 34mm throttle body
• Starter
  Electric with optional auxiliary recoil
• Transmission
  Five-speed automatic Dual-Clutch Transmission (DCT) with reverse
• Driveline
  Direct front and rear driveshafts with torque-sensitive locking front differential
• Front Suspension
  Independent double-wishbone; 7.3-inch travel
• Rear Suspension
  Independent dual-arm; 8.5-inch travel
• Front Brakes
  Dual 193mm discs
• Rear Brake
  170mm disc
• Front Tires
  24 x 8-12
• Rear Tires
  24 x 10-11
• Length
  84.5 inches
• Width
  47.4 inches
• Height
  47.2 inches
• Wheelbase
  51.0 inches
• Seat Height
  35.4 inches
• Ground Clearance
  9.6 inches
• Curb Weight
  686 pounds (includes all standard equipment, required fluids and a full tank of fuel)
• Fuel Capacity
  3.9 gallons, including 1.3-gallon reserve
• Turning Radius
  11.5 feet
• Towing Capacity
  848 pounds
• Front Rack Capacity
  66.0 pounds
• Rear Rack Capacity
  133.0 pounds
• Model ID
  TRX420FA6
• Emissions
  Meets current EPA and CARB (California) off-road emissions standards.
• Available Colors
  Hero Red, Blue, TrueTimber® Atera Camo
• Important Safety Information
  Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.
• Duration
  Transferable, one year included, limited warranty
• Optional Extended
  Extended coverage available with a HondaCare® Protection Plan
